744760047A
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7NH 600MA 60 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 961
Can ship immediately
Pricing:
- 1$0.38
Quote It
Technical Details
- Series:WE-KI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:4.7 nH
- Tolerance:±0.2nH
- Current Rating (Amps):600 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):60mOhm Max
- Q @ Freq:60 @ 1GHz
- Frequency - Self Resonant:5.8GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.055" (1.40mm)
