AISC-0603F-220J-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 70MA 11.4 OHM SMD
- CategoryFixed Inductors
- Datasheet AISC-0603F-220J-T Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$0.4
- 3,000$0.153
- 6,000$0.144
- 15,000$0.1395
- 30,000$0.135
- 75,000$0.1305
Quote It
Technical Details
- Series:AISC-0603F
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±5%
- Current Rating (Amps):70 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):11.4Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:2.5 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.039" W (1.60mm x 1.00mm)
- Height - Seated (Max):0.047" (1.20mm)
