LQW2BHNR27J03L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 270NH 190MA 2 OHM SMD
- CategoryFixed Inductors
- Datasheet LQW2BHNR27J03L Datasheet
-
ECAD Model
- Share
In Stock: 1,035
Can ship immediately
Pricing:
- 1$0.44
- 2,000$0.1755
Quote It
Technical Details
- Series:LQW2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Non-Magnetic
- Inductance:270 nH
- Tolerance:±5%
- Current Rating (Amps):190 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):2Ohm Max
- Q @ Freq:15 @ 25.2MHz
- Frequency - Self Resonant:550MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:10 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.059" W (2.00mm x 1.50mm)
- Height - Seated (Max):0.070" (1.78mm)
