744762139A
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 39NH 1A 100 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 264
Can ship immediately
Pricing:
- 1$0.44
- 2,000$0.277
Quote It
Technical Details
- Series:WE-KI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:39 nH
- Tolerance:±5%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):100mOhm Max
- Q @ Freq:60 @ 350MHz
- Frequency - Self Resonant:1.5GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.102" L x 0.083" W (2.60mm x 2.10mm)
- Height - Seated (Max):0.075" (1.90mm)
