CW252016-R33G
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 330NH 500MA 1.05OHM SM
- CategoryFixed Inductors
- Datasheet CW252016-R33G Datasheet
-
ECAD Model
- Share
In Stock: 546
Can ship immediately
Pricing:
- 1$0.47
- 2,000$0.15476
- 4,000$0.14566
- 6,000$0.14244
Quote It
Technical Details
- Series:CW252016
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:330 nH
- Tolerance:±2%
- Current Rating (Amps):500 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.05Ohm Max
- Q @ Freq:45 @ 100MHz
- Frequency - Self Resonant:570MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:25 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.071" (1.80mm)
