VLS252012HBU-6R8M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 970MA 440 MOHM
- CategoryFixed Inductors
- Datasheet VLS252012HBU-6R8M Datasheet
-
ECAD Model
- Share
In Stock: 696
Can ship immediately
Pricing:
- 1$0.54
- 2,000$0.2295
- 4,000$0.216
- 6,000$0.20925
- 10,000$0.2025
- 50,000$0.189
Quote It
Technical Details
- Series:VLS-HBU
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):970 mA
- Current - Saturation (Isat):1.28A
- Shielding:Shielded
- DC Resistance (DCR):440mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:-
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.047" (1.20mm)
