ELL-4GG1R2N
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.2UH 1.9A 50 MOHM SMD
- CategoryFixed Inductors
- Datasheet ELL-4GG1R2N Datasheet
-
ECAD Model
- Share
In Stock: 931
Can ship immediately
Pricing:
- 1$0.55
- 2,000$0.22525
- 4,000$0.212
- 6,000$0.20538
- 10,000$0.19875
- 50,000$0.1855
Quote It
Technical Details
- Series:G
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:1.2 µH
- Tolerance:±30%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):2.4A
- Shielding:Shielded
- DC Resistance (DCR):50mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.150" L x 0.150" W (3.80mm x 3.80mm)
- Height - Seated (Max):0.055" (1.40mm)
