LQH43NH1R2K03L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.2UH 1.1A 51.6 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 660
Can ship immediately
Pricing:
- 1$0.75
Quote It
Technical Details
- Series:LQH43
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.2 µH
- Tolerance:±10%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):51.6mOhm Max
- Q @ Freq:20 @ 1MHz
- Frequency - Self Resonant:100MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.110" (2.80mm)
