SCIHP0718-1R0M
Signal Transformer
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 7A 18.5 MOHM SMD
- CategoryFixed Inductors
- Datasheet SCIHP0718-1R0M Datasheet
-
ECAD Model
- Share
In Stock: 942
Can ship immediately
Pricing:
- 1$0.7
- 1,500$0.30817
Quote It
Technical Details
- Series:SCIHP0718
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):7 A
- Current - Saturation (Isat):11.5A
- Shielding:Shielded
- DC Resistance (DCR):18.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:200 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.268" W (7.30mm x 6.80mm)
- Height - Seated (Max):0.071" (1.80mm)
