744045150
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 730MA 500 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 653
Can ship immediately
Pricing:
- 1$0.8
- 500$0.51
Quote It
Technical Details
- Series:WE-LQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):730 mA
- Current - Saturation (Isat):1.24A
- Shielding:Unshielded
- DC Resistance (DCR):500mOhm Max
- Q @ Freq:45 @ 1MHz
- Frequency - Self Resonant:26MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.114" (2.90mm)
