AIUR-02H-680K
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 810MA 161 MOHM TH
- CategoryFixed Inductors
- Datasheet AIUR-02H-680K Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$0.84
- 10$0.73322
- 100$0.52322
- 500$0.43951
- 1,000$0.35579
- 2,500$0.33486
Quote It
Technical Details
- Series:AIUR-02H
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±10%
- Current Rating (Amps):810 mA
- Current - Saturation (Isat):1.36A
- Shielding:Unshielded
- DC Resistance (DCR):161mOhm Max
- Q @ Freq:20 @ 2.52MHz
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-25°C ~ 85°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.472" (12.00mm)
