PA4340.152NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 6A 25 MOHM SMD
- CategoryFixed Inductors
- Datasheet PA4340.152NLT Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$0.96
- 2,000$0.42655
- 4,000$0.40145
- 6,000$0.38891
- 10,000$0.37636
Quote It
Technical Details
- Series:PA4340.XXXNLT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):6 A
- Current - Saturation (Isat):10A
- Shielding:Shielded
- DC Resistance (DCR):25mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.213" W (6.00mm x 5.40mm)
- Height - Seated (Max):0.118" (3.00mm)
