SDR0906-680KL
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 1A 310 MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR0906-680KL Datasheet
-
ECAD Model
- Share
In Stock: 1,354
Can ship immediately
Pricing:
- 1$0.89
- 600$0.41055
- 1,200$0.33235
- 3,000$0.3128
- 6,000$0.3059
Quote It
Technical Details
- Series:SDR0906
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±10%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1.4A
- Shielding:Unshielded
- DC Resistance (DCR):310mOhm Max
- Q @ Freq:20 @ 2.52MHz
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.413" W (12.50mm x 10.50mm)
- Height - Seated (Max):0.248" (6.30mm)
