SRR4528A-100M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 1.76A 0.88OHM SMD
- CategoryFixed Inductors
- Datasheet SRR4528A-100M Datasheet
-
ECAD Model
- Share
In Stock: 378
Can ship immediately
Pricing:
- 1$1.02
Quote It
Technical Details
- Series:SRR4528A
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):1.76 A
- Current - Saturation (Isat):1.13A
- Shielding:Shielded
- DC Resistance (DCR):88mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:35MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard, Corner Terminals
- Supplier Device Package:-
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.110" (2.80mm)
Related Products
FIXED IND 2.2UH 5.5A 36 MOHM SMD
