SLF10145T-101M1R0-H
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100UH 1.1A 240 MOHM
- CategoryFixed Inductors
- Datasheet SLF10145T-101M1R0-H Datasheet
-
ECAD Model
- Share
In Stock: 318
Can ship immediately
Pricing:
- 1$1.58
- 500$0.80975
- 1,000$0.71978
- 2,500$0.69728
- 5,000$0.67479
- 12,500$0.6523
Quote It
Technical Details
- Series:SLF-H
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:100 µH
- Tolerance:±20%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):1A
- Shielding:Shielded
- DC Resistance (DCR):240mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.398" L x 0.398" W (10.10mm x 10.10mm)
- Height - Seated (Max):0.189" (4.80mm)
