ELL-8UV4R7N
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 4.2MA 12 OHM SMD
- CategoryFixed Inductors
- Datasheet ELL-8UV4R7N Datasheet
-
ECAD Model
- Share
In Stock: 501
Can ship immediately
Pricing:
- 1$1.57
- 500$0.68274
- 1,000$0.60688
- 2,500$0.58792
- 5,000$0.56895
- 12,500$0.54998
Quote It
Technical Details
- Series:ELL-8UV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±30%
- Current Rating (Amps):4.2 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):12Ohm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max):0.256" (6.50mm)
