CLF10060NIT-1R5N-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 9.3A 8.06 MOHM
- CategoryFixed Inductors
- Datasheet CLF10060NIT-1R5N-D Datasheet
-
ECAD Model
- Share
In Stock: 353
Can ship immediately
Pricing:
- 1$1.73
- 500$0.8869
- 1,000$0.78835
- 2,500$0.76372
- 5,000$0.73908
- 12,500$0.71445
Quote It
Technical Details
- Series:CLF-NI-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±30%
- Current Rating (Amps):9.3 A
- Current - Saturation (Isat):11A
- Shielding:Shielded
- DC Resistance (DCR):8.06mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.398" L x 0.394" W (10.10mm x 10.00mm)
- Height - Seated (Max):0.248" (6.30mm)
