SRP1250-6R8M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 11A 18.5MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP1250-6R8M Datasheet
-
ECAD Model
- Share
In Stock: 426
Can ship immediately
Pricing:
- 1$1.72
- 500$0.7344
- 1,000$0.6528
- 2,500$0.6384
Quote It
Technical Details
- Series:SRP1250
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):11 A
- Current - Saturation (Isat):21A
- Shielding:Shielded
- DC Resistance (DCR):18.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.547" L x 0.531" W (13.90mm x 13.50mm)
- Height - Seated (Max):0.232" (5.90mm)
