744778239
Würth Elektronik Midcom- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 390UH 300MA 2.94 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 570
Can ship immediately
Pricing:
- 1$2.36
Quote It
Technical Details
- Series:WE-PD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:390 µH
- Tolerance:±20%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):340mA
- Shielding:Shielded
- DC Resistance (DCR):2.94Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:4.4MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
- Height - Seated (Max):0.134" (3.40mm)
