RLF7045T-121MR55-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120UH 550MA 480 MOHM
- CategoryFixed Inductors
- Datasheet RLF7045T-121MR55-D Datasheet
-
ECAD Model
- Share
In Stock: 1,167
Can ship immediately
Pricing:
- 1$2.77
- 1,000$1.32026
- 3,000$1.27766
- 5,000$1.23508
Quote It
Technical Details
- Series:RLF-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:120 µH
- Tolerance:±20%
- Current Rating (Amps):550 mA
- Current - Saturation (Isat):800mA
- Shielding:Shielded
- DC Resistance (DCR):480mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.268" W (7.30mm x 6.80mm)
- Height - Seated (Max):0.189" (4.80mm)
