IHLP1616BZERR22M01
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220NH 13A 8 MOHM SMD
- CategoryFixed Inductors
- Datasheet IHLP1616BZERR22M01 Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$1.12
- 4,000$1.065
- 8,000$1.0295
Quote It
Technical Details
- Series:IHLP-1616BZ-01
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:220 nH
- Tolerance:±20%
- Current Rating (Amps):13 A
- Current - Saturation (Isat):24A
- Shielding:Shielded
- DC Resistance (DCR):8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:151MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.175" L x 0.160" W (4.45mm x 4.06mm)
- Height - Seated (Max):0.079" (2.00mm)
