NRH3012T4R7MNV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 1.06A 156 MOHM
- CategoryFixed Inductors
- Datasheet NRH3012T4R7MNV Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$0.32
- 2,000$0.12751
- 4,000$0.12043
- 6,000$0.11335
- 10,000$0.1098
- 50,000$0.10272
- 100,000$0.09918
Quote It
Technical Details
- Series:NR, H Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):1.06 A
- Current - Saturation (Isat):1A
- Shielding:Shielded
- DC Resistance (DCR):156mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:50MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.047" (1.20mm)
