NRS5020T150MMGJ
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 1.2A 198 MOHM SMD
- CategoryFixed Inductors
- Datasheet NRS5020T150MMGJ Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$0.3
- 800$0.13923
- 1,600$0.11934
- 4,000$0.11271
- 5,600$0.10608
- 20,000$0.10277
- 40,000$0.09945
- 80,000$0.09614
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):1.2 A
- Current - Saturation (Isat):1.1A
- Shielding:Shielded
- DC Resistance (DCR):198mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-25°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.193" L x 0.193" W (4.90mm x 4.90mm)
- Height - Seated (Max):0.079" (2.00mm)
