SRN4026-151M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 220MA 1.92OHM SM
- CategoryFixed Inductors
- Datasheet SRN4026-151M Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$0.42
- 3,000$0.136
- 6,000$0.133
Quote It
Technical Details
- Series:SRN4026
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:150 µH
- Tolerance:±20%
- Current Rating (Amps):220 mA
- Current - Saturation (Isat):220mA
- Shielding:Semi-Shielded
- DC Resistance (DCR):1.92Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:6MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.098" (2.50mm)
