SRR5028-470Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 820MA 250MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR5028-470Y Datasheet
-
ECAD Model
- Share
In Stock: 196
Can ship immediately
Pricing:
- 1$0.84
- 400$0.37953
- 800$0.2907
- 1,200$0.27455
- 2,800$0.2584
- 10,000$0.2527
Quote It
Technical Details
- Series:SRR5028
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±30%
- Current Rating (Amps):820 mA
- Current - Saturation (Isat):650mA
- Shielding:Shielded
- DC Resistance (DCR):250mOhm Max
- Q @ Freq:7 @ 2.52MHz
- Frequency - Self Resonant:13MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.228" L x 0.228" W (5.80mm x 5.80mm)
- Height - Seated (Max):0.118" (3.00mm)
