SRP5015TA-220M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.2A 466 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP5015TA-220M Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$1.5
- 3,500$0.54276
Quote It
Technical Details
- Series:SRP5015TA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Carbonyl Powder
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.2 A
- Current - Saturation (Isat):1.7A
- Shielding:Shielded
- DC Resistance (DCR):466mOhm Max
- Q @ Freq:10 @ 100kHz
- Frequency - Self Resonant:13MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.205" L x 0.205" W (5.20mm x 5.20mm)
- Height - Seated (Max):0.059" (1.50mm)
