SRP7050TA-470M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 1.9A 330 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP7050TA-470M Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$1.5
- 800$0.58969
- 1,600$0.555
- 4,000$0.54276
Quote It
Technical Details
- Series:SRP7050TA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Carbonyl Powder
- Inductance:47 µH
- Tolerance:±20%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):2.7A
- Shielding:Shielded
- DC Resistance (DCR):330mOhm Max
- Q @ Freq:15 @ 100kHz
- Frequency - Self Resonant:8MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.287" L x 0.260" W (7.30mm x 6.60mm)
- Height - Seated (Max):0.197" (5.00mm)
