7447720222
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2MH 300MA 4.73 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 556
Can ship immediately
Pricing:
- 1$0.96
- 10$0.909
- 50$0.847
- 140$0.753
- 280$0.69
Quote It
Technical Details
- Series:WE-TI
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 mH
- Tolerance:±5%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):350mA
- Shielding:Unshielded
- DC Resistance (DCR):4.73Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:1.1MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder (Open)
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.394" (10.00mm)
