HC9-1R0-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 23.7A 1.87 MOHM
- CategoryFixed Inductors
- Datasheet HC9-1R0-R Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
- 1$4.02
- 450$2.42928
Quote It
Technical Details
- Series:HC9
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:1 µH
- Tolerance:±15%
- Current Rating (Amps):23.7 A
- Current - Saturation (Isat):41A
- Shielding:Unshielded
- DC Resistance (DCR):1.87mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.528" L x 0.516" W (13.40mm x 13.10mm)
- Height - Seated (Max):0.295" (7.50mm)
