36401E3N3ATDF
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3NH 380MA 450 MOHM
- CategoryFixed Inductors
- Datasheet 36401E3N3ATDF Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$0.19
- 1,000$0.07871
Quote It
Technical Details
- Series:3640, Sigma Inductors
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Thin Film
- Material - Core:-
- Inductance:3.3 nH
- Tolerance:±0.2nH
- Current Rating (Amps):380 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):450mOhm Max
- Q @ Freq:13 @ 500MHz
- Frequency - Self Resonant:6GHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:500 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
- Height - Seated (Max):0.015" (0.37mm)
