NLV25T-180J-EF
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18UH 130MA 4.8 OHM SMD
- CategoryFixed Inductors
- Datasheet NLV25T-180J-EF Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$0.24
- 10$0.21257
- 100$0.14614
- 500$0.12487
- 1,000$0.09564
Quote It
Technical Details
- Series:NLV-EF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:18 µH
- Tolerance:±5%
- Current Rating (Amps):130 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):4.8Ohm Max
- Q @ Freq:25 @ 2.52MHz
- Frequency - Self Resonant:24MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.075" (1.90mm)
