AISC-1008HQ-R10J-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 100NH 1A 160 MOHM SMD
- CategoryFixed Inductors
- Datasheet AISC-1008HQ-R10J-T Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$0.31
- 2,000$0.1278
- 4,000$0.1207
- 6,000$0.1136
- 10,000$0.11005
- 50,000$0.10295
- 100,000$0.0994
Quote It
Technical Details
- Series:AISC-1008HQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:100 nH
- Tolerance:±5%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):160mOhm Max
- Q @ Freq:62 @ 350MHz
- Frequency - Self Resonant:820MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:50 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.102" L x 0.083" W (2.60mm x 2.10mm)
- Height - Seated (Max):0.075" (1.90mm)
