SRR1210-3R3Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 9A 10 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRR1210-3R3Y Datasheet
-
ECAD Model
- Share
In Stock: 208
Can ship immediately
Pricing:
- 1$1.27
- 250$1.05435
- 500$0.90374
- 750$0.85353
- 1,250$0.80333
- 2,500$0.78561
Quote It
Technical Details
- Series:SRR1210
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±30%
- Current Rating (Amps):9 A
- Current - Saturation (Isat):10.5A
- Shielding:Shielded
- DC Resistance (DCR):10mOhm Max
- Q @ Freq:15 @ 7.96MHz
- Frequency - Self Resonant:44MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.472" L x 0.472" W (12.00mm x 12.00mm)
- Height - Seated (Max):0.394" (10.00mm)
