FP1008R5-R150-R

Technical Details

• Series:FP1008
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:-
• Material - Core:Ferrite
• Inductance:150 nH
• Tolerance:±10%
• Current Rating (Amps):79 A
• Current - Saturation (Isat):64A
• Shielding:Shielded
• DC Resistance (DCR):0.17mOhm

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.425" L x 0.315" W (10.80mm x 8.00mm)
• Height - Seated (Max):0.315" (8.00mm)
