NRH3012TR47NNV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 1.9A 39.6 MOHM
- CategoryFixed Inductors
- Datasheet NRH3012TR47NNV Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$0.55
- 2,000$0.12712
- 4,000$0.12005
- 6,000$0.11299
- 10,000$0.10946
- 50,000$0.1024
- 100,000$0.09887
Quote It
Technical Details
- Series:NR, H Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:470 nH
- Tolerance:±30%
- Current Rating (Amps):1.9 A
- Current - Saturation (Isat):2.6A
- Shielding:Shielded
- DC Resistance (DCR):39.6mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:160MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.047" (1.20mm)
