SRN2012-2R2M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 1.3A 186MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN2012-2R2M Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$0.35
- 2,000$0.11475
- 4,000$0.10838
- 6,000$0.102
- 10,000$0.09975
Quote It
Technical Details
- Series:SRN2012
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):1.3 A
- Current - Saturation (Isat):1.6A
- Shielding:Semi-Shielded
- DC Resistance (DCR):186mOhm Max
- Q @ Freq:13 @ 1MHz
- Frequency - Self Resonant:70MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.047" (1.20mm)
