PM1812-1R8J-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.8UH 390MA 650MOHM SM
- CategoryFixed Inductors
- Datasheet PM1812-1R8J-RC Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
- 1$0.4
- 500$0.17778
- 1,000$0.13617
- 2,500$0.1286
- 5,000$0.12104
- 12,500$0.11837
Quote It
Technical Details
- Series:PM1812
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:1.8 µH
- Tolerance:±5%
- Current Rating (Amps):390 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):650mOhm Max
- Q @ Freq:50 @ 7.96MHz
- Frequency - Self Resonant:60MHz
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.134" (3.40mm)
