SDR6603-220M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 800MA 370MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR6603-220M Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$1
- 600$0.3978
- 1,200$0.3536
- 3,000$0.3458
Quote It
Technical Details
- Series:SDR6603
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):700mA
- Shielding:Unshielded
- DC Resistance (DCR):370mOhm Max
- Q @ Freq:16 @ 2.52MHz
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
- Height - Seated (Max):0.115" (2.92mm)
