SRR1005-182K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.8MH 160MA 5.7OHM SMD
- CategoryFixed Inductors
- Datasheet SRR1005-182K Datasheet
-
ECAD Model
- Share
In Stock: 240
Can ship immediately
Pricing:
- 1$1.04
- 600$0.4131
- 1,200$0.3672
- 3,000$0.3591
Quote It
Technical Details
- Series:SRR1005
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.8 mH
- Tolerance:±10%
- Current Rating (Amps):160 mA
- Current - Saturation (Isat):230mA
- Shielding:Shielded
- DC Resistance (DCR):5.7Ohm Max
- Q @ Freq:65 @ 252kHz
- Frequency - Self Resonant:1.4MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.500" L x 0.394" W (12.70mm x 10.00mm)
- Height - Seated (Max):0.205" (5.20mm)
