7447732133
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 430MA 970 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 3,127
Can ship immediately
Pricing:
- 1$0.98
- 3,000$0.613
Quote It
Technical Details
- Series:WE-PD2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:33 µH
- Tolerance:±10%
- Current Rating (Amps):430 mA
- Current - Saturation (Isat):700mA
- Shielding:Unshielded
- DC Resistance (DCR):970mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:24MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:3521
- Size / Dimension:0.138" L x 0.118" W (3.50mm x 3.00mm)
- Height - Seated (Max):0.094" (2.40mm)
