7447720221
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 1A 450 MOHM TH
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 262
Can ship immediately
Pricing:
- 1$0.79
Quote It
Technical Details
- Series:WE-TI
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:220 µH
- Tolerance:±10%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1A
- Shielding:Unshielded
- DC Resistance (DCR):450mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:3.8MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.394" (10.00mm)
