CV201210-8R2K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2UH 15MA 1.1 OHM SMD
- CategoryFixed Inductors
- Datasheet CV201210-8R2K Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$0.02957
- 4,000$0.02571
Quote It
Technical Details
- Series:CV201210
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:8.2 µH
- Tolerance:±10%
- Current Rating (Amps):15 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):1.1Ohm Max
- Q @ Freq:45 @ 4MHz
- Frequency - Self Resonant:26MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:4 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.057" (1.45mm)
