ASMCI-0805-2R2M-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 220MA 280 MOHM
- CategoryFixed Inductors
- Datasheet ASMCI-0805-2R2M-T Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$0.09792
- 4,000$0.09792
- 8,000$0.09216
- 12,000$0.08928
- 28,000$0.0864
- 100,000$0.08064
Quote It
Technical Details
- Series:ASMCI-0805
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):220 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):280mOhm
- Q @ Freq:-
- Frequency - Self Resonant:50MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.041" (1.05mm)
