NLCV32T-1R5M-EFR

Technical Details

• Series:NLCV-EF
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.5 µH
• Tolerance:±20%
• Current Rating (Amps):1.4 A
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):114mOhm Max

• Q @ Freq:15 @ 7.96MHz
• Frequency - Self Resonant:80MHz
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:7.96 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1210 (3225 Metric)
• Supplier Device Package:1210
• Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
• Height - Seated (Max):0.094" (2.40mm)
