AISC-0402HP-47NJ-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47NH 420MA 550 MOHM
- CategoryFixed Inductors
- Datasheet AISC-0402HP-47NJ-T Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$0.10118
- 10,000$0.10118
Quote It
Technical Details
- Series:AISC-0402HP
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:47 nH
- Tolerance:±5%
- Current Rating (Amps):420 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):550mOhm Max
- Q @ Freq:22 @ 200MHz
- Frequency - Self Resonant:2.4GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:200 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0402 (1005 Metric)
- Supplier Device Package:0402 (1005 Metric)
- Size / Dimension:0.039" L x 0.022" W (1.00mm x 0.55mm)
- Height - Seated (Max):0.024" (0.60mm)
