PE-0402CD1N0JTT

Technical Details

• Series:0402CD
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ceramic
• Inductance:1 nH
• Tolerance:±5%
• Current Rating (Amps):1.36 A
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):45mOhm

• Q @ Freq:13 @ 250MHz
• Frequency - Self Resonant:6GHz
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:250 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0402 (1005 Metric)
• Supplier Device Package:0402 (1005 Metric)
• Size / Dimension:0.047" L x 0.026" W (1.19mm x 0.66mm)
• Height - Seated (Max):0.024" (0.61mm)
