AISC-0603-R037G-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 37NH 600MA 250 MOHM
- CategoryFixed Inductors
- Datasheet AISC-0603-R037G-T Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$0.10608
- 3,000$0.10608
Quote It
Technical Details
- Series:AISC-0603
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:37 nH
- Tolerance:±2%
- Current Rating (Amps):600 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):250mOhm Max
- Q @ Freq:35 @ 250MHz
- Frequency - Self Resonant:2.2GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.071" L x 0.044" W (1.80mm x 1.12mm)
- Height - Seated (Max):0.040" (1.02mm)
