LB2518T6R8MV
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 195MA 195 MOHM
- CategoryFixed Inductors
- Datasheet LB2518T6R8MV Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$0.1186
- 2,000$0.1186
Quote It
Technical Details
- Series:LB
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):195 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):195mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:38MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1007 (2518 Metric)
- Supplier Device Package:-
- Size / Dimension:0.098" L x 0.071" W (2.50mm x 1.80mm)
- Height - Seated (Max):0.079" (2.00mm)
