SRN2510-R68M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680NH 2.8A 55 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRN2510-R68M Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$0.14184
- 2,000$0.13875
Quote It
Technical Details
- Series:SRN2510
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 nH
- Tolerance:±20%
- Current Rating (Amps):2.8 A
- Current - Saturation (Isat):2.9A
- Shielding:Semi-Shielded
- DC Resistance (DCR):55mOhm Max
- Q @ Freq:9 @ 1MHz
- Frequency - Self Resonant:160MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.040" (1.02mm)
