B78148E1471M009

Technical Details

• Series:BC
• Package:Tape & Box (TB)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:470 nH
• Tolerance:±20%
• Current Rating (Amps):5 A
• Current - Saturation (Isat):8.5A
• Shielding:Unshielded
• DC Resistance (DCR):27mOhm Max

• Q @ Freq:60 @ 1MHz
• Frequency - Self Resonant:400MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Radial
• Supplier Device Package:-
• Size / Dimension:0.157" Dia x 0.374" L (4.00mm x 9.50mm)
• Height - Seated (Max):-
